〓〓 INTERFACE DESCRIPTION 〓〓
— 8 —
White Balance
Auto/Manual/Auto tracking/Push/Indoor/Outdoor/Color
Temperature
Exposure
Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
Anti-Flicker
OFF,50Hz,60Hz
Image Flip
Support
Mirroring
Support
Focus
Auto/Manual
Iris
Auto/Manual
Electronic-shutter
Auto/Manual
Gamma
Support
ND Filter
Support
Backlight
Compensation
Support
IP Streaming
Video Encoding
H.264/H.265
Bitrate Control
Variable bitrate(VBR), Constant bitrate(CBR)
Bitrate Range
1Mbps~120Mbps
Network Port Speed
1000M
Protocol
NDI®, NDI®|HX,SRT, HTTP, RTSP, RTMP, ONVIF, VISCA
over IP(TCP&UDP), VISCA, PELCO P/D,SSDP, FreeD, NTP,
RTP Multicast, WebRTC
Pan/Tilt Movement
Preset
Remote controller: 10; Serial port: 256; Accuracy：0.1°
Pan Rotation Angle
-170° ~+170°
Tilt Rotation Angle
-90° ~+90°
Pan Rotation Speed
0.1°~80°/s
Tilt Rotation Speed
0.1°~60°/s
I/O Interface
Control Port
RS232,RS485,RS422,RJ45,USB, NDI®|HX
Video Port
NDI®, NDI®|HX, HDMI2.0, 3G-SDI, 12G-SDI, USB Type-C
Audio Port
Min XLR (with phantom power), POE++(IEEE802.bt)
Tally
Support
POE++
Support
Genlock
Support
Daisy Chain
Support
General
Input Voltage
DC12V, POE++(IEEE802.bt)
Operating Temperature
-10℃~ 50℃
Operating Humidity
≤80%
Dimension (L×W×H)
232.5mm×264mm×269mm
Net Weight
4.6KG (10.15LBS)
Color
Black/White
