4
PRODUCT HIGHLIGHTS
• Adopts most advanced ISP, 1/2.8 inch 2.4MP sensor, providing 1080P60 full HD video resolution.
• Big optical lens: 20x optical zoom , with 60 degree field of view.
• 1080p60 video over IP, H.264, H.265 encoding.
• Support NewTek NDI video transmission and control.
• NDI|HX, HDMI (or 3G-SDI), USB outputs, fit for different application.
• White Balance, Exposure, Focus, Iris can be adjusted automatically or manually.
• Support POE: one single CAT5/6 to get video, control and power supply.
• Special Focusing Algorithm: fast and precise focusing performance when zooming or moving.
• Smooth PTZ mechanical design, accurate pan tilt motor control.
• 128 presets supported; Exposure parameter and white balance parameter can be saved in presets (in manual mode).
• Standard Sony VISCA, IP VISCA, PELCO-P, PELCO-D control protocol; IP VISCA over both TCP and UDP.
• Daisy chain supported, max 7 cameras connected in VISCA protocol.
• Image flip function, support upside-down installation.
• Fast video format switch: less than 3 seconds.
• Supported field upgrade for ISP, ARM, FPGA and USB.
• USB3.0 port compatible with USB2.0 output.
• Support RS232/RS485/UVC control.
• Standard UVC1.5 protocol, seamlessly compatible with major video conferencing software and platform.
• OSD menu in English and Chinese supported. IP address, streaming resolution and size can be set in OSD menu.
CAMERA SPEC
Camera
Drive+ SE 20X-SDI
Drive+ SE 20X-HDMI
Part Number
TLC-300-IP-20(NDI)-SDI
TLC-300-IP-20(NDI)-HDMI
Video Format
SDI:
1920*1080P60/50/30/25/59.94/29.97/24
1920*1080i60/50/59.94
1280*720P60/50/30/25/59.94/29.97
HDMI:
1920*1080P60/50/30/25/59.94/29.97/24
1920*1080i60/50/59.94
1280*720P60/50/30/25/59.94/29.97
USB:
1920*1080P60/50/30/25(USB3.0); 1280*720P60/50/30(USB3.0)
1280*720P25(USB3.0&USB2.0); 1024*576P30(USB3.0&USB2.0)
960*540P30(USB2.0); 640*360P30(USB2.0); 512*288P30(USB2.0)
IP:
Main Stream: 1920*1080@3~60; 1280*720@3~60; 1024*576@3~60
Sub Stream: 1280*720@3~60; 1024*576@3~60; 640*360@3~60
NDI:
1920*1080@3~60, 1280*720@3~60, 1024*576@3~60,
640*360@3~60 (low bandwidth mode)
Video Interface
SDI, NDI|HX, USB3.0
HDMI, NDI|HX, USB3.0
Sensor
1/2.8”2.4MP CMOS sensor
Zoom
f 4.9～98mm(20X), F1.5- 3.0, View Angle: 60°(Far)-3.2°(Near)
Rotation Angle
Pan: -170° ~ +170°; Tilt: -30° ~ +90°
Rotation Speed
Pan: 0°~120°/s ; Tilt: 0°~80°/s
Preset:
Remote controller: 10; RS232: 128; Accuracy: 0.1°
