CHAPTER 1
Introduction
Description
The MS-4002 is a complete 4-channel master station and system power supply (24 VDC, up to 3.5Amps total power) in a
single unit. Simply plug it into any AC power outlet from 100 to 240 volts, add a microphone or headset, connect intercom
stations to the backpanel, and it’s ready to communicate. It has 1-, 2-, 3- and 4-channel connectors, so a separate breakout
panel is not needed to mix multiple intercom stations. The MS-4002 fits in a standard 19-inch equipment rack and is 1 RU
(Rack Unit) high. A basic MS-4002 can communicate with four (4) intercom channels. This number can be increased by
connecting an optional EMS-4001 Expansion Station. Each EMS-4001 adds four (4) channels, and up to four (4) of these
expansion stations can be connected for a total of 20 channels.
Features
• Auto-Sensing Headset Connector
Built-in auto-sensing headset connectors that dynamically
determines whether the headset connected to the system is
dynamic or electret.
• Speaker Station or Headset Station
Uses the built-in speaker for listening and adds an optional
Telex MCP-90 series gooseneck panel microphone for
talk-back. Turn off the speaker volume and plug in any
Telex headset for private communication.
• PA (Public Address) Output, with PA Key
Uses the intercom microphone to talk over a PA system.
• Back-lit Keys
Uses back-lit keys to improve visibility in low-light
environments.
• Incoming Call Indications
Uses red flashing call lights with an optional beep tone for
call indications, if desired.
• Mic Kill Key
Turns off all microphones for a specific channel to
quickly clear traffic on the channel.
• Program Input for each Channel
Connects any line-level audio source for monitoring
speaker or headset, or for routing to an intercom channel.
The program audio to the channel can be set to interrupt
while the MS-4002 operator is talking on the channel.
• Listening with Externally Powered Speakers
Connect externally powered speakers and monitor
channels 1, 2, 3, and 4.
• Expandable
Adds more channels by connecting optional EMS-4001
Expansion Stations. Each EMS-4001 adds four (4)
additional powered channels (up to 20 channels).
• Clear - ComCompatible
Runs in unbalanced mode.
