19

All Talk

You can talk to all intercom stations that currently have their listen keys activated. This applies to all channels of the

MS-4002, as well as all the talk channels of any EMS-4001 Expansion Stations.

To use the all talk function, do the following:

NOTE: If you are using manual microphone activation instead of Vox, make sure the proper microphone switch is

turned on (either Headset or Panel Mic).

1. Press and hold the All Talk key while talking.

2. Release the All Talk key when finished.

NOTE: To insure that the All Talk key is never accidently left in the on position, it does not latch.

Public Address (PA)

You can create a PA system with the MS-4002 if the PA output on the back panel of the MS-4002 is connected to a public

address system.

To use the PA system function, do the following:

NOTE: If you are using the manual microphone activation instead of Vox, make sure the proper microphone switch

is turned on (either Headset or Panel Mic).

1. Press and hold the PA key while talking.

2. Release the key when finished.

NOTE: To insure that the PA key is never accidently left in the on position, it does not latch.

Turning the Program Input On and Off

To turn the program input on and off, do the following:

1. Insure the program inputs have been connected at the back panel and the program sources are ON.

2. Press and hold the Mic Kill key for two (2) seconds, then release it.

It should now be glowing green to indicate the MS-4002 is in programming mode.

3. The current status of the program inputs is indicated by the Talk keys:

a. If Channel 1 talk is lit, program 1 is activated to channel 1.

b. If Channel 2 talk is lit, program 2 is activated to channel 2.

c. Tap either Talk key to turn the program input for that channel on or off.

NOTE: You can also turn the Program Input ON and OFF on channels 3 and 4.

4. When the program inputs are configured as desired, tap the Mic Kill key to exit programming mode and return to

normal operation.

5. Adjust Program 1, 2, 3, and 4 via the trimmers on the rear panel of the MS-4002.

NOTE: See “MS-4002 Reference View” on page 8.
