1. Technical speciﬁcations

1.1. TWIN Modulator ref. 5806

The technical characteristics described are dened for a maximum ambient temperature of 45°C (113ºF). Forced ventilation is used for higher temperatures.

Video

Bandwidth: 0,00005 ... 5 MHz Dierencial phase: < 4°

Input level (75 ohm): 1 Vpp Chroma/luma Delay: < 100 ns

Modulation depth: 72,5 ... 90 % Chroma/luma Delay: > 52 dB

Dierencial gain: < 4 % Flatness: < +1 dB

Audio

Bandwidth: 0,04 ... 15 KHz S/N ratio: > 45 dB

Impedance: 10000 ohm Flatness: < ±1 dB

Pre-emphasis: 50 µS Input level: >-15 <7 dBm

Deviation (1KHz/1.7Vpp input): program. (see table) Distortion (1KHz dev. ± 30KHz): < 1 %

RF output

Output frequency: 46 ... 862 MHz Return losses: 10 dB (14 typ)

Impedance: 75 ohm

Audio carrier precision:

VHF < 25 KHz

UHF < 50 KHz

Output level: 80 ± 5 dBµV

Regulation margin: > 15 dB

Video carrier stability:

VHF < 15 KHz

UHF < 30 KHz

Level stability: ± 3 dB

Pa/Pv distance: -12, -16 (prog.) Carrier ratio (MHz): 4,5 / 5,5 / 6 / 6,5

IF frequency: 38,9 MHz

Band spurious level

46 ... 862MHz:

55 dBc min. > 60 dBc typ

Frequency steps: 250 KHz (prog.)

C/N (5MHz): > 56 dB Through losses (46 - 862 MHz): < 1.5 dB

General

Power supply: 24V

Protection index: IP20

Consumption 24V: 300 mA
