Technical specications
References 563822
INPUTS
VIDEO Connectors
4 sets - 1x RCA for Video (CVBS)
AUDIO Connectors 4 sets - 2x RCA for Analog Audio (L, R)
OUTPUT
Connectors “F” Female (loop-through combiner input)
ENCODING
PROFILE
VIDEO
Output Format MPEG-2 / H.264
Resolution
480i & 576i
Supports auto-scan for input resolution
Aspect Ratio 4:3, 16:9 and pass through
GOP 10, 12, 15, 16, 18, 20, 24 or 30
Transport rate Variable
Video bit rate Variable
AUDIO
Output format MPEG1 Layer 2
Sampling rate kHz 48
Output bitrate Variable
OUTPUT
RF
Connectors 1x “F” Female
Frequency Range MHz 46 - 862
Max output level dBµV +115 (+103 with loop-through)
MER dB >40 (typ)
Spurious dBc -60
Impedance Ω 75
I/Q Phase Error º <1
I/Q Amplitude Imbalance % <1
QAM
Modulation format 16, 32, 64, 128, 256
BaudRate Mbaud 6,9
Roll-o % 15
Code Reed Solomon
Spectrum Mode Normal / Inverted
Frequency Step KHz 250
COFDM
Modulation format QPSK, 16QAM, 64QAM
Guard Interval 1/4, 1/8, 1/16, 1/32
FEC 1/2, 2/3, 3/4, 5/6, 7/8
Bandwidth MHz 6, 7, 8
Cell_id Editable
Frequency Step KHz 125 / 166
PSI PARAMETERS
Transport Stream ID Editable
Original Network ID Editable
Network ID Editable
Logical Channel Number Editable
NIT Version Manual / Automatic
SDT Version Manual / Automatic
Type LCN Generic / UK / NorDig V1 / NorDig V2
Network Name Editable
Service PID Editable
Service Name Editable
Service ID Editable
MONITORING / CONTROL
Local control Full conguration with LCD handheld programmer
Local monitoring
LOOP status LED
OUTPUT status LED
TEMP status LED
CH1/CH2 - CH3/CH4 status LEDs
Ethernet status LEDs
Remote monitoring Centralized web based remote control, management, alarms, and software upgrades
Control Daisy-chain integrated ethernet switch
GENERAL
Power supply Vdc 24
Power disipation W <16
Operating Temperature ºF / ºC 32 to 113 / 0 to 45
