EN
17
How to manage the menus:
- The selected option in the menu is displayed
blinking.
- To move around the menu, use or keys.
Nota: If the menu is longer than one page, use the
or to scroll the menu and access the options
that are hidden.
- To browse the normal menus (shown with ).
Press to enter. Press to go back.
- In the nal menus (shown with ), press and hold
to accept. Press the key to return to normal
menu.
The following gures show the di erent menus.. As
shown, if you select SYSTEM, you can change the
name of the CDC H/E Manager to enable better
tracking, set the date and time, select the menu
language and nally display the Start Menu to
check the software versions and reference number
of the unit.
6. Installation of CDC H/E
Manager
The basic installation of the CDC H / E MANAGER
start with a local setting, either through the LCD
Programmer Ref 7234 or by the Local Web in IP
alias (169.254.1.254).
Programmer LCD ref. 7234
Insert the programmer in the socket (“PRGM”)
that is located on the front of the CDC module.
First, it will display the rmware version of the
programmer:
V:5.02
PCT Firmware
version
------------
Afterwards, it is displayed the information about
the CDC module connected to the programmer.
(device name, SW version and serial number).
Finally, the main menu appears.
HELP Û
SYSTEM Û
CONF.COMMÛ
UPGRADE Û
000000000000
CDC H/E
MANAGER
00.00.00000
RESET Û
System
VERSION Û
TIME-DATE Û
CDC NAME Û
LANGUAGE Û
HELP Û
SYSTEM Û
CONF.COMMÛ
UPGRADE Û
spanish
LANGUAGE
>
english
000000000000
CDC H/E
MANAGER
00.00.00000
Temp. 31.5ø
12:05:25
07/10/2011
ÛCDC NAME
CDCT0X000000
SYSTEM
Communications settings
HELP Û
SYSTEM Û
CONF.COMMÛ
UPGRADE Û
GSM-GPRS Û
CONF.COMM.
ETHERNET Û
LINK SERV.Û
NETMASK Û
ETHERNET
DHCP Û
IP Û
LINK SERV.
IP Û
PORT Û
GSM-GPRS
PIN-PUK Û
OPERATOR Û
GATEWAY Û
