DVBS2 - COFDM CI

Important safety instructions

General installation conditions

• Before handling or connecting the equipment, please read this

manual.

• In order to reduce the risk of  re or electric shock, do not expose the

equipment to rain or moisture.

• Do not take the cover o the equipment without disconnecting it

from the mains.

• Do not obstruct the equipment’s ventilation system.

• Please allow air circulation around the equipment.

• The equipment must not come into contact with water or even be

splashed by liquids. Do not place containers with water on or near the

equipment if it is not adequately protected.

• Do not place the equipment near sources of heat or in excessively

moisture conditions.

• Do not place the equipment where it may be a ected by strong

vibrations or knocks.

• This symbol indicates that the equipment complies with

the requirements of CE mark.

Inputs/Outputs/Connections description

The unit (Fig. 1) is provided with:

1. IF satellite input

2. IF satellite output

3. RF input

4. RF output

5. Module power supply input

6. Status LED

7. Control BUS connector

8. Slot CAM

9. Programmer / PC connector

10. Programmer unit 7234

Introduction

The DVBS2 transmodulator with COFDM CI receives a satellite transponder

in some DVBS (QPSK) or DVBS2 (QPSK or 8PSK) modulation formats and

demodulates it by obtaining an MPEG-2 transport package.

The MPEG2 transport package is then modulated in COFDM format and

converted to the output channel (UHF or VHF and with a maximum

bandwidth of 8 MHz) using an agile up-converter.

Additionally, it incorporates a Common Interface slot for inserting a

conditional access module (CAM) to permit the unscrambling of services.

The programming of the transmodulator operating parameters (input

frequency, output channel, modulation format and adaptation of services

mainly) is performed through the universal programmer (ref. 7234).

NOTE: The complete user manual is available in the CD

that is provided with the product.

Technical speciﬁ cations

Satellite

Demodulator

Input frequency 950 - 2150 MHz Through loss < 1,5 dB typ.

Symbol rate 10-30 Mbaud (QPSK- 8PSK) Modulation

DVB-S2 (QPSK, 8PSK)

DVB-S (QPSK)

Frequency steps 1 MHz Internal FEC

LDPC (9/10, 8/9, 5/6, 4/5, 3/4, 2/3, 3/5,

1/2, 1/4, 1/3, 2/5)

Input/Output connectors “F” female External FEC BCH (Bose-Chaudhuri-Hocquenghem)

Input impedance 75 ohm. Roll-o factor 20%, 25%, 35%

LNB power supply 13/17V/ OFF 22KHz (ON/OFF) Input VSWR 10 dB min.

COFDM

Modulator

Modulation format QPSK, 16QAM, 64QAM Scrambling DVB ET300744

Guard interva 1/4, 1/8, 1/16, 1/32 Interleaving DVB ET300744

FEC 1/2, 2/3, 3/4, 5/6, 7/8 Cell_id Selectable

Bandwidth 7 MHz, 8 MHz Output spectrum Normal / Inverted (Selec.)

RF output

Output frequency

177 - 266 / 474 - 858 MHz (CH mode)

45- 862 MHz (frequency mode)

Through loss < 1,5 dB typ.

Frequency steps 166 KHz Return loss > 12 dB typ.

Maximum output level 80±5 dBμV (progr.) Input/Output connectors “F” female.

Attenuation >15 dB (prog) Output impedance 75 ohm.

General

Consumption*

24V

: 280 mA typ. (no CAM inserted; LNB power OFF)

24V

: 330 mA typ. (CAM inserted; LNB power OFF)

24V

: 500 mA typ. (no CAM inserted; LNB power ON)

24V

: 540 mA typ. (CAM inserted; LNB power ON)

Protection index IP20

* The unit’s consumption with CAM will depend on the type of CAM being used. For the LNB it is considered a standard consumption of 300 mA.

The technical characteristics described are de ned for a maximum ambient temperature of 45°C (113ºF). Forced ventilation is used for higher temperatures.
