When taking a real measurement, use the shortest
possible ground lead and signal path to minimize probe-
induced ringing and distortion on the measured signal.
Signal with a short length ground
lead
Signal with a long ground lead
Getting on-screen help for settings HelpEverywhere™
HelpEverywhere™ is a mode that displays graphics and short text descriptions when you access the menus for most oscilloscope
settings. This is very useful for when you are first learning the functions of oscilloscope controls.
You can enable HelpEverywhere™ content for all supported settings, or enable it for specific function groups, such as T
rigger controls,
Vertical controls, and so on.
1. Push the Help front-panel button.
2. Push the HelpEverywhere™ side-menu button to display the menu. All HelpEverywhere™ content is set to Off by default except for
the Measurement category, which is On.
Getting acquainted with the oscilloscope
TBS1000C Series Oscilloscopes User Manual 45
