Do not float the common terminal above the rated voltage for that terminal.
Do not operate without covers Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage
exposure is possible.
Avoid exposed circuitry Do not touch exposed connections and components when power is present.
Do not operate with suspected
failures
If you suspect that there is damage to this product, have it inspected by qualified service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in
doubt about safety of the product, turn it of
f and disconnect the power cord. Clearly mark the product to
prevent its further operation.
Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when
damaged. Do not use probes or test leads if they are damaged, if there is exposed metal, or if a wear
indicator shows.
Examine the exterior of the product before you use it. Look for cracks or missing pieces.
Use only specified replacement parts.
Do not operate in wet/damp
conditions
Note: Be aware that condensation may occur if a unit is moved from a cold to a warm
environment.
Do not operate in an explosive
atmosphere
Keep product surfaces clean
and dry
Remove the input signals before you clean the product.
Provide proper ventilation To ensure proper cooling, keep the sides and rear of the instrument clear of obstructions. Slots and
openings are provided for ventilation and should never be covered or otherwise obstructed. Do not push
objects into any of the openings.
Provide a safe working
environment
Always place the product in a location convenient for viewing the display and indicators. Avoid improper
or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use
may result in serious injury
. Be sure your work area meets applicable ergonomic standards. Consult with
an ergonomics professional to avoid stress injuries. Use care when lifting and carrying the product. This
product is provided with a handle or handles for lifting and carrying.
Use only the Tektronix rackmount hardware specified for this product.
Probes and test leads
Before connecting probes or test leads, connect the power cord from the power connector to a properly grounded power outlet.
Keep fingers behind the finger guards on the probes.
Remove all probes, test leads and accessories that are not in use.
Use only correct Measurement Category (CA
T), voltage, temperature, altitude, and amperage rated probes, test leads, and adapters for
any measurement.
Beware of high voltages Understand the voltage ratings for the probe you are using and do not exceed those ratings. Two ratings are
important to know and understand:
• The maximum measurement voltage from the probe tip to the probe reference lead
•
The maximum floating voltage from the probe reference lead to earth ground
These two voltage ratings depend on the probe and your application. Refer to the Specifications section of
the manual for more information.
Important safety information
TBS1000C Series Oscilloscopes User Manual 16
