(1
5 To make the electric connection betwe-
en the two appliances, attach the hob’s
connector to oven’s connector.
6 Complete the definitive positioning of
the oven, ensuring that the cardan teles-
copic shafts are firmly in position and
that the telescopic pipes are well-aligned
when inserted so that sliding is
quite simple.
7 Position the controls on the front of the
oven.
8 To operate the control knobs, they first
have to be pressed in, and then turned
in order to release the safety device.
Rear view of the Control Panel:
If the cardan telescopic shafts are too
short, extensions can be added (not provi-
ded, but available as an accessory).
These are added by pressing, and they
are fixed by the cover that is included.
fig. 6
Flexible supply cable
Connector
Protective box for electrical assembly
fig. 5
Retention clips
Pins
37
