8
EN
Install Instruction
Installation in cabinet
1. Cabinet size requirement.(The skirting
board and back of the cabinet shall be
provided with a through heat dissipation
channel)
min.
200 cm
2
min.
200 cm
2
5
40
m
m
5
5
0
m
m
5
6
4
m
m
1770 mm
Min. 2200mm
Max. 2500mm
1772 mm
Min.
550 mm
1785 mm
2. Push the refrigerator into the cabinet
and adjust it to make sure the edge fold
of top baffle completel touch the top
edge of the cabinet, and the limit hook
of supporting leg completely touch the
bottom edge of the cabinet.
3. Fix the top baffle to the top of the cabinet
inner with screws, then install the screw
caps.
4. Open the door of cabinet the maximum
angle, and open the door of the
refrigerator to the corresponding position.
Sliding the block to make sure inner edge
align with the door edge of refrigerator,
then fix the block to the door of cabinet
with screw and install screw caps.
