7
EN
Install Instruction
Door reversing (optional)
1. Power off the refrigerator, and remove all
objects from the door trays.
2. Dismantle upper hinge cover, upper hinge
and hole cap of the other side, remove the
refrigerating door.
3. Dismantle the middle hinge, the screws
,the screws hole caps and remove the
freezer door.
4. Dismantle the bottom hinge, hole caps
and screws, Install the bottom hinge
shaft and adjust foot on other side of the
bottom hinge, then install the hinge on
the other side.
5. Dismantle the screw, sleeve pipe and
stopper from the refrigerating door and
freezer door, and the support on the lower
cover of the refrigerating door is also
removed.Then install them on the other
side of the doors in order.
Exchange the position of sleeve pipe and
hole cap at the top cover of refrigerating
door,and install the upper hinge sleeve on
the freezer door to the hole on the other
side of axis sleeve.
6. Put the freezer door on bottom hinge ,
install the middle hinge, the screws and
the screw hole caps.
screw
middle hinge
screw
hole cap
Upper Hinge Cover
Upper Hinge
Sleeve Pipe
Hole Cap
sleeve pipe
stopper screw
Shaft
Screw Cap
Screw
hole cap
Middle Hinge
Screw
Hole Cap
stopper
