Flex Zone function

Through this function, it is possible

to enable two cooking zones work

together, and to select a power level

and to activate the timer function for

both zones.

To activate this function, press the

sensor

/ (14). By doing so, the

decimal points (4) of the linked plates

will light up and the value “0” will be

shown on their power indicators (3).

The clock timer indicator (12) will

show three segments indicating the

activated zones. In case your model

has several zones with “Flex Zone”,

you can select the desired option

by pressing the sensor

/ (14)

before assigning the power to the

chosen zone. You will have a few

seconds to perform the next operation;

otherwise, the function will be disabled

automatically.(see ﬁ g 7).

After the “Flex Zone” is selected, you

can assign the power by touching

any of the “sliders” cursors (2) of

one of the linked zone. The power

level and its variations are displayed

simultaneously on the power indicators

(3) of both zones.

To disable this feature, you should

touch the sensor

/ (14) again.

Also, when the function is disabled,

the levels of powers and functions

assigned to the related zones are

cleared.

Safety switch oﬀ function

If due to an error one or several

heating zones do not switch oﬀ , the

appliance will be automatically discon-

nected after a set amount of time (see

table 1).

Table 1

Selected

power

level

MAXIMUN

OPERATING TIME

(in hours)

0 0

1 8

2 8

3 5

4 4

5 4

6 3

7 2

8 2

9 1

10 or 5 minutes,

readjusts to level 9

(depending on model)

When the “safety switch oﬀ ” function

has been triggered, a 0is displayed if

the glass surface temperature is not

dangerous for the user or an H if there

is a burn risk.

Keep the control panel of the

heating areas clean and dry at all

times.

In the event of operating pro-

blems or incidents not mentioned in

this manual, disconnect the

appliance and contact the TEKA

technical service.

Suggestions and

recommendations

* Use pots or pans with thick, comple-

tely ﬂ at bottoms.

* Do not slide pots and pans over the

glass because they could scratch it.

* Although the glass can take knocks

from large pots and pans without

sharp edges, try not to knock it.

* To avoid damaging the ceramic

glass surface, do not drag pots and

pans over the glass and keep the

undersides of them clean and in

good condition.

* Recommended diameters of the pot

bottom (see ‘’Technical Data Sheet’’

supplied with the product).

Try not to spill sugar or pro-

ducts containing sugar on the glass

as while the surface is hot these

could damage it.

Cleaning and maintenance

To keep the appliance in good condition,

clean it using suitable products and

implements once it has cooled down.

This will make the job easier and avoid

the build-up of dirt. Never use harsh

cleaning products or tools that could

scratch the surface, or steam-operated

equipment.

Light dirt not stuck to the surface can

be cleaned using a damp cloth and a

gentle detergent or warm soapy water.

However, for deeper stains or grease

use a special cleaner for ceramic hot

plates and follow the instructions on

the bottle. Dirt that is ﬁ rmly stuck due

to being burned repeatedly can be

removed using a scraper with a blade.

Slight tinges of colour are caused by

pots and pans with dry grease residue

underneath or due to grease between

the glass and the pot during cooking.

These can be removed using a nickel

scourer with water or a special cleaner

for ceramic hot plates. Plastic objects,

sugar or food containing a lot of sugar

that have melted onto the surface

must be removed immediately using

a scraper.

Metallic sheens are caused by dragging

metal pots and pans over the glass.

These can be removed by cleaning

thoroughly using a special cleaner

for ceramic glass hot plates, although

you may need to repeat the cleaning

process several times.

Warning:

A pot or pan may become

stuck to the glass due to a product

having melted between them. Do not

try to lift the pot while the heating

zone is cold! This could break the

glass.

Do not step on the glass or lean

on it as it could break and cau-se

injury. Do not use the glass as a

surface for placing objects.

TEKA INDUSTRIAL S.A. reserves the

right to make changes to its manuals

that it deems necessary or useful,
