40
USE
KEY LOCK FUNCTION
Lock Function ( ): this function prevents the hob from being accidentally switched on (child safety
lock). To activate it, the sensor must be pressed for about three seconds (the warning light comes
on). It is not possible to make the heating areas work if is active. If the heating elements are still
working, it is possible to switch them off while is active. This function is deactivated by pressing the
sensor for two seconds, for all the configurations.
RESIDUAL HEAT
Every plate has a device which indicates the presence of residual heat. On the display, after switching off
any plate, an may appear. This signal indicates that the cooking area is still very hot. It is possibile
to start cooking food again even when the is visibile, by reactivating the heating element required.
SWITCHING OFF THE PLATES
The plates switch off when the relative operating power display indicates 0. The plate will be
automatically deactivated five seconds after the 0 appears on the display. If the plates are hot, the
indicating the presence of residual heat will appear. To immediately switch off an element, simply touch
the and keys together, or the key until 0 appears on the display.
SWITCHING OFF THE HOB
The hob is switched off by pressing the symbol for one second, even if the plates are operating; all
the plates will be deactivated and the hob will switch off completely. If the plates are hot, the
indicating the presence of residual heat will appear after switching off. There is a heat protection system
installed inside the hob. If the temperature exceeds 95 °C, the hob switches off automatically. This is to
prevent excessive temperature from damaging the internal components.
Models: IG 940 1G AI AL DR CI - IG 940 2G AI AL CI
FRONT LEFT BACK LEFT BACK CENTRAL
FRONT RIGHT BACK RIGHT FRONT CENTRAL
Every time the hob is reconnected to the electricity supply, the control panel lock is active and the
relative led in on.
After removing the control panel lock (by pressing the symbol for 1 second), switch on the hob by
pressing the key for a few seconds. If no function is activated within 10 seconds, the hob will switch
off automatically. The associated heating element is indicated next to every control area. Identify
the heating element to activate ( ) and then activate it using the and keys, regulating the
level of cooking required on a scale o 1 to 9. With the heating element set on 9 it is possible, pressing the
key, to activate the “fast boil” function (booster), indicated with a P on the display. The heating
element will work at maximum power for 10 minutes, after which it will return to level 9, issuing a beep.
