Gas conversion
Important!
Any alteration that is to be made to the
appliance to convert it to a different
type of gas should only be carried out
by a qualified technician.
Information for Technical Assis-
tance: whenever the type of gas or the
appliance’s pressure is changed, the new
regulation plate should be placed on top of
the old one so that the new features can
be seen after the change.
The tasks involved in conversion are:
* Replace the injectors.
* Adjust the taps’ minimums.
The injectors required for each gas type
are shown in table 1.
To replace the injectors, follow these ins-
tructions:
1 Remove the grids and upper parts of the
burner so that the injector can be seen.
2 Using a number 7 pipe spanner, remove
the injectors and replace them with the
new ones. Take care to press the injector
down firmly so that there is no leakage.
3 Replace the grid and burners that were
previously removed.
When the injectors have been changed,
this is how to adjust the minimums:
1 Turn the burners on to their minimum.
2 Pull the taps’ controls firmly upwards to
remove them.
3 Use a slim, grooved screwdriver to turn
the screw located to the right or in the
centre of the gas tap’s shaft (the flame
increases when you turn to the left and
decreases when you turn to the right).
4 When properly adjusted, check that the
flame does not go out when you turn the
knob quickly from maximum to mini-
mum.
TEKA INDUSTRIAL, S.A. assumes no
responsibility for any hob malfunction if the
gas conversion or the adjustment of the
burners’ minimums has not been carried
out by TEKA’s official personnel.
Table 1
GB_61401134_en.qxd 27.02.2015 14:52 Page 10
BURNERS
DESCRIPTION
GAS
NORMAL
PRESSURE
mbar
NORMAL
RATE
I/h
g/h
INJEKTOR
DIAMETER
1/100mm
NOMINAL
HEAT INPUT (W)
Min.
Max.
N°
1
SEMI RAPID
BUTANE G30
PROPANE G31
NATURAL G20
BUTANE G30
PROPANE G31
NATURAL G20
BUTANE G30
PROPANE G31
NATURAL G20
28-30
37
20
28-30
37
20
28-30
37
20
218
214
68
68
98 Z
400
400
400
1000
1000
1000
500
500
500
1750
1750
750
750
750
3000
3000
3000
51
51
72 X
117 Y
127
125
73
71
286
167
95
RAPID
AUXILIARY
2
3
BY PASS
1/100 mm
41
Adj.
32
Adj.
30
Adj.
11
85
85
