• If you are ironing a fabric comprising a mixture of fibres: adjust the temperature

to the most delicate fibre.

• If you put your thermostat in the “MIN” position, the iron does not become hot.

Using the water spray trigger (spray)

• When ironing with the steam or dry function, press the spray trigger several times

in succession to remove stubborn wrinkles – fig.6.

Obtaining more steam

• Set the thermostat control to “MAX” or “•••”.

• Press the turbo steam button from time to time – fig.7.

• To avoid water dripping onto your clothes, wait a few seconds before pressing again.

Smoothing garments vertically

• Hang the garment on a hanger and hold the fabric using one hand. The steam

is very hot so you should always do this with the garment on a hanger – never

while someone is wearing it.

• Set the thermostat control to “MAX” – fig.8.

• Pulse the turbo steam button – fig.7 and move from top to bottom – fig.9.

Dry Iron function

• Adjust the temperature to the fabric being ironed.

• Set the steam control to – fig.1.

• You can iron when the light goes out.

Additional functions

Gliss/Glide Protect

autoclean soleplate

(depending on model)

• Your iron is equipped with a catalytic self-cleaning soleplate.

• Its exclusive coating removes all impurities generated by normal use.

• It is recommended that you always rest your iron on its support base to preserve its self-cleaning coating.

Auto-stop safety function

(depending on model)

• The electronic system cuts the power and the auto-stop light flashes if the iron

is placed on its support base for more than 8 minutes or left flat for more than

30 seconds – fig.10.

• To restart the iron, simply shake it gently until the light stops flashing.

Anti-drip function

• The automatic steam selection function is based on the fabric being ironed, which is integrated into your iron,

reduces the steam flow at low temperatures and prevents the iron from dripping onto your clothes.

Cleaning and maintenance

Self-cleaning

• Put the steam button on “MAX”.

• Place the iron on its base with a full tank and set the thermostat to the

“MAX”position.

• When the light goes out, disconnect the iron and place it over a sink.

• Set the thermostat to the "MIN" position.

• Remove the anti-calc valve.

• Shake the iron lightly and horizontally above a sink until part of the water (with

the impurities) flows from behind the appliance – fig.21.

• Once you have finished this operation, replace the anti-calc valve, inserting it

until you hear a click – fig.20.

• Plug in your iron and let it stand on its base for 2 minutes in order to clean the

soleplate.

• Unplug your iron and when the soleplate is lukewarm, dry it with a soft cloth.

Check that there is

water in the tank before

using the spray trigger.

Hold the iron a few

centimetres from the

fabric so as not to burn

delicate fabrics.

In normal use, the auto-

stop light is on!

1800133458 FV96XX E0_110x154 11/07/14 13:09 Page3
