Technical specifications
Measurement range 20°C / 42,2°C
Screen resolution 0,1°C
Precision from 32°C to 42°C: +/- 0,2°C
< 32°C and > 42°C: +/- 0,3°C
Operation conditions - +16°C / +35°C
room temperature Relative humidity less than 85%
Storage conditions - 20°C / +80°C
Relative humidity less than 95%
Energy source 1 lithium battery 3V type CR2032
Service life: approximately 5000 measures
In compliance with the European directive 93/42 (Medical appliances) and EN 12470-5
(medical thermometer).
CE 0120 marking
Comments: these technical specifications may be subject to modifications to improve the
appliance, without prior warning.
Made in China by Hubdic CNS
Imported and distributed by TEFAL SAS
Italia - EC Representative: Bremed Italia S.r.l. Via Alviano 4/1 Gorizia - Italia
TEFAL SAS BP 89 74156 RUMILLY Cedex FRANCE
Before first use
Installing the battery
The appliance is delivered with a lithium battery 3V (CR2032) already in place.
At the first use, open the battery cover then remove the strip which ensures the protection of the
battery (fig. 1/fig. 2). Replace the cover (fig. 3).
Functionning
Ear measurement
• Remove the protection cap.
• To switch on press and hold the button until the indications in fig. 4 are displayed in the
screen the appliance automatically displays the Ear mode. The screen shows the corresponding
function fig. 5 and the luminous diode corresponding to the symbol blink 5 times.
• Gently pull the ear upwards and backwards to straighten the ear canal. Insert the thermometer
into the ear canal fig. 6.
Description
1 - Lens
2 - Probe
3 - Battery compartment
4 - Luminous diodes to show temperature mode : ear or forehead
5 - Screen
6 - Take temperature and memory function button
7 - On/Off and Ear or forehead temperature Mode button
8 - Protection/vertical storage cap.
Precautions for use
This ear and forehead thermometer receives the infra-red rays emitted by the skin’s surface and
in the ear drum area. It allows you to check your child’s temperature easily. This is how to use
the appliance:
• The TEFAL thermometer is exclusively dedicated to take ear or forehead temperatures.
We would like to re-iterate that this appliance does not replace the advice of a doctor. In case of
doubt or fever, contact your doctor. TEFAL cannot be held responsible for poor interpretation of results.
The simple take of temperature cannot be considered as a medical advice, DO NOT
modify the proportion of any drugs prescribed by your doctor without seeking medical advice first.
• To ensure the reading is accurate, the probe and the lens must be absolutely clean.
• Do not use the thermometer if it has been dropped or shows any signs of damage
• Always place the protection cap back after use.
• In cases of movement from one room to another, wait for half an hour minimum before using
the appliance.
• Wait for half an hour after physical training, bathing or eating before measuring temperature.
• Keep the thermometer out of reach of children.
• Do not expose the thermometer:
- To any warm sources (radiator, sun rays, ...)
- To dust or humidity.
• Never immerse the thermometer in liquid.
• Do not touch the lens with your fingers.
BODY TEMPERATURE: the normal human body temperature varies during the day. It is measured
along a scale of values defined according to the part of the body where the temperature is taken:
- Rectal measurement: 36,6° - 37,8°C
- Axillary measurement (under the arm): 34,7° - 37,3°C
- Oral measurement (in the mouth) or forehead: 35,5° - 37,5°C
- Ear measurement: 35,8° - 37,8°C
Warning, this appliance is not suitable for dectecting hypothermia.
Average temperatures
Forehead Ear Rectal Oral Axillary
temperature temperature temperature temperature temperature
36,1°C 36,4°C 37,0°C 36,6°C 36,1°C
GB
24 25
TE211422 Notice Thermo Auri 13 L 13/10/06 12:29 Page 24
