Owner’s manual Owner’s manual18 19
EN EN
IMPORTANT: Plug the device into power mains only AFTER the device has been completely
and correctly assembled.
1. Place the motor unit onto a level, dry, smooth, waterproof worktop.
2. Place the cup on the motor unit so that the arrow on the base with the blades points to
the open padlock symbol.
3. Turn clockwise until it snaps into place.
4. Place the lid on the jar and turn it clockwise until it locks in place. Place the measuring
cup on the lid.
5. To use the travel jar instead of the cup, unscrew the knife base from the cup and screw it
to the travel jar.
Speed adjustments:
• Pulse: Rotate and keep the knob to “P” (function is active as long as you keep the knob in
that position). Release the knob to turn o the function. Suggested for ingredients that
require short time processing (e.g. nuts).
• 1
st
mode: Low speed for delicate foods processing with a folding motion. Suggested for
combining wet and dry ingredients as well as chopping.
• 2
nd
mode: High speed for breaking down ingredients. Suggested for liquefying.
Preparing ingredients
The ingredients to be processed need to be precut, peeled and pitted if necessary. Please
note, very hard skin and pits can damage the blades of the device. When the ingredients are
too big, the device may jam. Prepare the ingredients accordingly.
Usually, a certain amount of drinking water or other liquids has to be added to facilitate the
smooth running of the appliance. The proportion of the food and water is 2:3. The amount of
mixture should not exceed the max level as indicated on the jar.
Using blender
1. Make sure the device is properly assembled. Connect the device to power supply mains
socket.
2. Insert ingredients into the jar (either through the opening in the lid or detach the lid).
3. Use the knob to set desired speed.
4. When processing is completed, turn it o and disconnect from power mains. Rotate the
jar anticlockwise and remove it from the motor unit.
ASSEMBLY
OPERATION
17. Do not use the product for purposes dierent from displayed in this operating manual.
This device is exclusively designed for food preparation. Do not place anything but food
in the appliance.
18. Do not leave the appliance unattended when it’s working. ALWAYS disconnect the
product from the mains supply when it is not in use.
19. Do not move the appliance while it is operating.
20. Don’t place very hot ingredients inside the appliance. Hot ingredients should be cooled
down prior to processing in the appliance (max. ingredient temperature is 60°C).
WARNING: When processing hot ingredients, they may be ejected via the opening in the
lid if the measuring cup is not installed (It is suggested not to process too much hot
ingredients at once, as it increases risk of ejecting from the blender and scalding). Make
sure to place the measuring cup into the lid when processing hot ingredients. Sudden
bursts of steam could also cause the lid to dislodge.
21. Appliance for indoor and household use only. The device is constructed to process
normal household quantities. Not for commercial use.
22. Always securely clamp in place all parts before the motor is turned on. Do not
disassemble while the device is operating. Note: the device can only be turned when the
device is properly assembled.
23. Never touch any moving parts when the device is connected to power supply. Make sure
the motor stops completely before disassembling. Do not touch the rotating parts with
spoons or any other kitchen utensils. Keep long hair and loose clothing away from the
rotating parts.
24. Always wait until the moving parts stop running, and then unplug the appliance before
opening, disassembling or removing the parts. If food sticks to the wall of the blender
jar, switch o the appliance and unplug it. Then use a spatula to remove the food from
the wall. Do not use metal utensils as they may damage the blades.
25. Do not store food in the blender jar. Do not use it in the microwave for reheating.
26. Some parts are dishwasher safe (jar, lid, measuring cup).
27. Do not use for more than 3 minutes at a time, allow motor to cool before reusing!
28. DO NOT use this device if the cord or the plug is damaged, the appliance is broken or has
previously been dropped.
29. Do not attempt to repair this appliance yourself. Only authorized and qualied
personnel may repair this device. Never disassemble the motor body of the device.
30. Do not use unauthorized accessories.
31. Producer of this product is not responsible for damages caused by inappropriate handle
and use of the device.
32. IMPORTANT: In order to ensure children‘s safety, please keep all packaging (plastic bags,
boxes, etc.) out of their reach. Caution! Do not allow small children to play with the foil
as there is a danger of suocation!
Wash the parts that will have contact with food before rst use. Rinse thoroughly with warm
water and allow to air dry. Never submerge the device motor unit in water or any other liquid.
BEFORE FIRST USE
