16 Owner’s manual 17
EN
Owner’s manual
EN
MOUNTING THE DEVICE
1. Insert the handle shaft into the opening
at the top of the main body with the
inset pointed towards the back. Push it in
until you hear it click into place.
2. To put the device in a standing position,
lift up the main body into a vertical
position until the inset on the tube
inserts into the groove on the floor head
and locks the mop in place.
1. Attach a dedicated cloth to the bottom of the
mop head. To do this, place the pad on the
oor, white side up, t the mop head to the
edges of the pad and push down on it.
2. Unscrew the cap of the water tank and ll it
using the included cup.
Note: It is recommended to use demineralized or
distilled water - this will help keep the device working
longer.
3. Plug power cable to the main socket.
4. The LED indicators will ash until the mop
motor reaches the temperature needed for
operation. After about 25 sec. the device is
ready to use.
5. To start steam generation, hold the mop head
with your foot and tilt the device back. The
operation of the engine will be audible. Steam
will begin to come out of the nozzle at the
bottom of the mop head.
6. To switch between power modes, press the
power mode button until the desired mode is
selected.
OPERATION
STEAM CLEANER OPERATION
7. To stop steam generation, turn the device to
the vertical position.
8. The device can also be used to freshen
carpets. To do that, mount plastic carpet
attachment on the mop head:
• put the attachment on the oor, the side
with latches up,
• insert the oor head into the front part of
the attachment, so the front edges of the
oor head are neatly aligned with the
edges of the attachment,
• push the mop down until the plastic
latches at the back of the attachment
clamp down on the oor head.
9. Further steps are the same as for standard
oor cleaning. Do not use carpet attachment
to clean smooth surfaces.
1. To remove the steam cleaner from the mop body,
press the two release buttons located at the
bottom of the tube at the same time, and then the
steam cleaner should be tilted slightly forward
and pulled upward.
2. Unscrew the cap of the water tank and ll it using
the included cup.
3. Attach the adapter to the steam outlet on the
steam cleaner and then apply the nozzle so that
the tabs slide into the grooves in the slot, then
turn clockwise until the nozzle locks onto the
adapter. To remove the adapter, press the button
on it and slide it o the steam cleaner.
4. To switch between power modes, press the power
mode button until the desired mode is selected.
5. Press and hold the steam release button to start
dispensing steam.
