20
Specifications
(20)
■ GENERAL
Power supply
AC 220 V to 240 V,
50/60 Hz
Power
consumption
45 W
Power
consumption in
standby mode
(Network Standby
Off)
0.3 W
Power
consumption in
standby mode
(Network Standby
On
*
1
)
2.0 W
Dimensions
(W×H×D)
430 mm × 98 mm ×
407 mm
Mass Approx. 12.3 kg
Operating
temperature range
5 °C to 35 °C
Operating humidity
range
35% to 80% RH
(no condensation)
*
1: Wired LAN or Wireless LAN
■ ANALOG OUTPUT SECTION
Channel 2 ch
Output level
BALANCED
2.2 Vrms (Super Audio CD) /
2.2 Vrms (CD)
UNBALANCED
2.2 Vrms (Super Audio CD) /
2.2 Vrms (CD)
Frequency
response
Super Audio CD 2 Hz to 50 kHz (-3 dB)
CD 2 Hz to 20 kHz (-3 dB)
THD+N
Super Audio CD 0.0006% (1 kHz, 0 dB)
CD 0.0015% (1 kHz, 0 dB)
S/N (IHF-A)
Super Audio CD
BALANCED: 121 dB
UNBALANCED: 118 dB
CD
BALANCED: 121 dB
UNBALANCED: 118 dB
Dynamic range
(IHF-A)
Super Audio CD
BALANCED: 110 dB
UNBALANCED: 110 dB
CD
BALANCED: 98 dB
UNBALANCED: 98 dB
■ DISC SECTION
Disc played
(8 cm or 12 cm)
Super Audio CD (2ch area
only), CD, CD-R, CD-RW
Pick up
Wavelength
650 nm (Super Audio CD),
790 nm (CD)
Laser power CLASS 1
Audio Output
(Disc)
2ch (FL, FR)
Format Super Audio CD, CD-DA
NORSK
Bølgelengde
650 nm (Super Audio CD),
790 nm (CD)
Laserstyrke
Ingen farlig stråling sendes ut
■ Bluetooth
®
SECTION
Bluetooth
®
system
specification
Bluetooth
®
Ver.4.2
Wireless
equipment
classification
Class 2 (2.5 mW)
Supported profiles A2DP, AVRCP
Supported codec AAC, SBC
Frequency band 2.4 GHz band FH-SS
Operating distance Approx. 10 m Line of sight
*
2
*
2: Prospective communication distance
Measurement environment:
Temperature 25 °C/Height 1.0 m
Measure in “Mode 1”
■ TERMINALS SECTION
Headphones Jack
Stereo, 6.3 mm
110 mW, 32 (VOL MAX)
USB (Front/Rear)
Type A Connecter
USB 2.0 High Speed
DC 5 V 500 mA (Front)
DC 5 V 1 A (Rear)
USB Mass Storage Class
File system FAT16, FAT32, NTFS
USB-B (PC) Rear, Type B Connecter
Ethernet interface
LAN
(100BASE-TX/10BASE-T)
Digital Input
Optical digital
input
Optical terminal
Coaxial digital
input
Pin jack
Format support LPCM
Analog output
BALANCED 3 pin XLR
UNBALANCED Pin jack
Digital output
Optical digital
output
Optical terminal
Coaxial digital
output
Pin jack
Format support LPCM
System port
System control 3.5 mm, Jack
