Technaxx TX-30 handleiding
Handleiding
Je bekijkt pagina 5 van 40
5
IP Camera:
No.
Name
Function
1
IR (Infrared) LEDs
The camera will use these in low-light conditions to generate a
black and white image, even in total darkness.
2
Lens
The business end of the camera. For a reliable and clear
image, ensure that the lens stays clean and unobstructed. To
clean, use a dedicated lens cleaning solution and cloth,
available from all good photography stores. (viewing angle:
H:57.4° V:42.8°)
3
Light Sensor
Detects the amount of light available and turns on the IR LEDs
when necessary.
4
Mounting bracket
The supplied mounting bracket can be screwed onto any flat
surface.
5
Power socket
Connect the power adapter here.(DC12V/1A)
6
RJ45 Ethernet
connector
For a wired connection, connect this to a spare port on your
home router. It’s recommended to use wired connection when
the distance between monitor and camera is beyond the
wireless transmission range.
7
Antenna
The included antenna connects here.
8
Housing
Made of metal. Protects the internal technique from weather.
9
Microphone
Allows the camera to pick up nearby sounds, and stream them
with the video.
10
PIR (Passive
infrared) Sensor
This is an electronic sensor that measures infrared light
radiating from objects (human body) in its field of view.
(viewing angle: H:120° V:60°)
Bekijk gratis de handleiding van Technaxx TX-30, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | Technaxx |
| Model | TX-30 |
| Categorie | Bewakingscamera |
| Taal | Nederlands |
| Grootte | 9889 MB |
Caratteristiche Prodotto
| Gebruikershandleiding | Ja |
| Kleur | Ja |
| Internationale veiligheidscode (IP) | IP66 |
| Plaatsing | Table, Wall |
| Montage gereedschap | Ja |
