Specifications
`
16
Forum™ (IMA-240)
Amplifier Output Power
50 W RMS, 2 x 25 W channels
Receiver Input
Infrared FM, 2 wireless mic channels
Modulation
Wide-band FM
Reception Frequencies
Ch. A: 2.08 MHz | Ch. B: 2.54 MHz
Deviation
10 kHz Nominal, 25 kHz Maximum
De-emphasis
50 µs
Tone Key
32.768 kHz
Infrared Wavelength
850 nm
External Sensor Input
2, RCA, powered ports
Connectivity Coverage
1,600 sq ft per sensor, up to 3 sensors supported
Total Harmonic Distortion
<1% @ 1 kHz
Frequency Response
40 Hz –18 kHz, ± 3 dB
Line Level Inputs
Rear Panel: DVD input, dual RCA, 0dB
Rear Panel: Computer input, 3.5mm, -10 dB
Front panel: Auxiliary input, 3.5 mm, -10 dB
Anti-Hum Balun
Present on Computer input
Line Outputs
Front panel: 3.5mm w/ gain control
Rear Panel: 3.5 mm w/ +10 dB gain control
Output Impedance
Rated Load: 4Ω minimum impedance
Equalization
3-band, ±10 dB
S/N Ratio
65 dB
Speaker Connection
4-pin Phoenix Connectors
Charger Output
5 VDC, USB
Power Supply
19 VDC / 3.5 A CE, CSA and UL Listed
Dimensions
8 1/2” W x 1 3/4” H x 7 1/2” D
Weight
1.7 lb.
Power Supply (AC-36)
Type
Regulated Switching Power Supply, CE, CSA and UL listed
Input Voltage
100-240 volts AV, 47-63 Hz
Output Voltage
19 VDC, 3.43 A
Power Output
65 watts max
