TV FRONT
Step 4
10
Get to know your TV
TV SIDE
F
G/H
J
I
G
E
A
D
USB 2.0
5V 0.5A
4K/
144Hz
4K/
144Hz
4K/
60Hz
(e)ARC
4K/
60Hz
CABLE/ANT
USB 3.0
5V 0.9A
IR RECEIVER Receives signal from
the TV remote.
STATUS LIGHT OF HANDS-FREE
VOICE CONTROL
Glows when you
activate the hands-free voice control.
(To learn more about the function,
go to page 15.)
A
B
C
POWER and OPTIONS BUTTON
Press once to open the menu.
Short click to change the menu and
long click to select.
HANDS-FREE VOICE CONTROL
MIC SWITCH
Toggle switch to enable or disable
the TV's integrated microphone.
TV BOTTOM
C B
I
ANTENNA/CABLE IN Connect an outdoor VHF/UHF
antenna or Cable TV feed.
OPTICAL (DIGITAL AUDIO OUT)
Connect an optical
cable to an external digital audio system.
J
USB PORT
Connect a USB device to access photos,
music and movies. Or connect the optional TCL
webcam to chat with friends using supported video
call apps.
E
H
HDMI PORTS
Highest quality audio/video connection.
Connect cable box, Blu-ray player, gaming console,
or other devices to your TV using HDMI cables.
ETHERNET Connect using an ethernet cable to your
home network router or switch.
F
HDMI ports 1 & 2: Supports up to 4K/144Hz
HDMI ports 3 & 4: Supports up to 4K/60Hz
G
HDMI eARC/ARC PORT Connect HDMI eARC/ARC
(audio return
channel) capable audio devices like
sound bars or
AV receivers.
D
POWER PORT Connect your TV
to the power source
with the
included power cable.
AUDIO OUT
CABLE/ANT
4K/
144Hz
4K/
144Hz
4K/
60Hz
(e)ARC
4K/
60Hz
USB 2.0
5V 0.5A
USB 3.0
5V 0.9A
50’’ 55’’/65’’/75’’/85’’
TV BACK
Note: 50’’ model has no subwoofers on the back.
