Specifications

Inputs

 Mic Connector: Balanced XLR, Input Impedance 1kOhm

 Mic Input Sensitivity @ 0dBFS -44dBu to +2dBu

 Mic Input Sensitivity @ 12dB headroom -56dBu to -10dBu

 EIN -126dBu @ max. mic amp gain, Rg = 150 Ohm

 MIDI In Connector: Standard 5 pin DIN

 Footswitch In: 1/4” 3 conductor phone jack

 Power Input: 12 VDC 300 mA, tip negative

Analog Outputs

 Main Output Connectors: Balanced TRS 1/4” jacks

 Output Impedance: 40 Ohm

 Output Level: +14 dBu @ 0dBFS

Input to Output Analog Audio Performance

 Dynamic Range, Mic. @ Min gain >108dB, 20 Hz - 20kHz *A-weighted

 Dynamic Range, Mic. @ -18dBu sensitivity > 104dB, 20hz - 20kHz*

 THD+ Noise, Mic. @ Min gain <-90dB

 Frequency Response, max gain -1.5dB @ 40 Hz, +0/-0.3 dB (200Hz to 20 kHz)

Conversion Characteristics

 Sample Rate 48 kHz, Converter AKM AK4620B

 AD / DA Conversion 24 bit, 128x oversampling bitstream

EMC & Safety

 Complies with EN 55103-1 and EN 55103-2

FCC part 15, Class B, CISPR 22, Class B

 Certified to IEC 65, EN 60065, UL6500 and

CSA E60065 CSA FILE #LR108093

Environment

 Operating Temperature 32° F to 122° F (0° C

to 50° C)

 Storage Temperature -22° F to 167° F (-30° C

to 70° C)

 Humidity Max. 90 % non-condensing

Supplementary

 Dimensions 130mm x 132mm x 41mm (5" x

5.25" x 1.5")

 Weight 1.5 lb. (0.72 kg)

 Warranty Parts and labor 1 year

All specifications and features subject to change

without notice.
