ted to the charger.

INSTRUCTIONS FOR USE

USE:

- Turn the appliance on, by using the on/o󰀨

switch. (B)

- The ON indicator lamp will light up. (C )

- Select the desired power.

- Slide one position for ECO speed / slide two

position for TURBO speed.

- To use the hand vacuum:

- Press the hand vacuum extraction button (H) on

the brush vacuum’s main body (E). (Fig. 2)

- Turn the appliance on, by using the on/o󰀨

switch. (I)

INSERTING THE MOP

(*) Only on the Inedit 29.6 Wash model

- Fill the mop’s water tank with water and, if ne-

cessary, add a few drops of detergent.

- Attach the water tank to the back the vacuum

cleaner’s brush base so that it clicks into posi-

tion and press the button to open the passage

for the water (Fig.3b)

- The mop can also be used dry.

- NOTE: The mop is machine washable.

FITTING AN ACCESSORY TO THE HAND

VACUUM:

- Press the hand vacuum extraction button (H) on

the brush vacuum’s main body (E). (Fig. 2)

- The hand vacuum is designed in such a way

that it allows the following accessories to be

tted: (use the combination that best meets your

requirements). (Fig.3)

- Furniture brush: Equipped with a brush at the

end, which brushes the surface as it is used.

- Crevice nozzle: Specially designed for getting

into cracks and di󰀩cult corners.

PARKING POSITION:

- This appliance has one parking position for

comfortable and straightforward storage.

FOLDING HANDLE:

- This appliance has a folded handle position for

easy storage. (Fig.4)

CLEANING

- Disconnect the charger from the mains and let it

cool before undertaking any cleaning task.

- Clean the appliance using a damp cloth with a

few drops of detergent and then dry it.

- Do not use solvents, or products with an acid or

base pH such as bleach, or abrasive products,

for cleaning the appliance.

- Do not submerge the appliance in water or any

other liquid, or place it under a running tap.

EMPTYING THE DUST BOX:

- Empty the vacuum deposit when dust is visible

though the transparent walls, when it is full, or

when the vacuum cleaner does not work to its

full potential.

- Press the hand vacuum extraction button (H) on

the brush vacuum’s main body (E). (Fig. 2)

- Disconnect the dust box from the appliance.

(Fig. 5)

- Remove the cloth lter and its protector. (Fig. 6)

- Empty the contents into a suitable rubbish

container.

- Clean the dust box lter.

- Attach the dust box to the appliance.

- To reassemble, follow the above instructions but

in reverse.

CHANGING THE FILTERS:

TO REMOVE FILTERS:

- Press the hand vacuum extraction button (H) on

the brush vacuum’s main body (E). (Fig. 2)

- Disconnect the dust box from the appliance.

(Fig 5)

- Remove the cloth lter and its protector. (Fig. 6)

- To reassemble the lter, proceed with the above

instructions, in reverse order.

- Cleaning the rotary brush:

TO REMOVE THE BRUSH:

- Turn the rotating button on the bottom of the

tting to the left in order to release the brush.

(Fig. 7)

- Remove the brush and clean.

- To reassemble, follow the above instructions but

in reverse.

SUPPLIES

- Supplies can be acquired from distributors and

authorised establishments (such as lters, etc. )

for your appliance model.

- Always use original supplies, designed speci-

cally for your appliance model.

HOW TO REMOVE THE BATTERIES FROM

THE INTERIOR OF THE DEVICE:

- Caution: It is important that the batteries are

fully discharged prior to its withdrawal from the
