20 TASCAM FR-AV2 V1.00
4-4. HOME screen
The HOME screen appears after the unit starts up.
Depending on the operation state, the HOME screen will appear
one of three ways.
The functions of the F1 – F4 buttons change according to the state.
Icon
Remaining
battery
charge
Remote controlTimecode
Audio monitoring
Inputs
Outputs
Function button functions
Project status
bar
Remaining battery charge / USB connection icon
This shows the remaining charge when operating with batteries.
This will switch to the USB icon when connected by USB.
Project status bar
This shows icons for the operation state, the time of the
recording/playback position and remaining microSD card
capacity, for example.
Status Indicator
Stopped
8
Recording
p
Recording
paused
p9
Playing
t
Paused
9
Inputs
This shows input settings and levels.
Outputs
This shows output settings and levels.
Timecode
This shows the timecode. (“Timecode selection” on page 57)
Audio monitoring
This shows the connection status of wireless audio monitoring
equipment. (“Wireless audio monitoring” on page 59)
Status Indicator
Connections
Disconnected
No
indicator
4. Preparation
REMOTE CONTROL
This shows the connection status of remote control devices.
(“Connecting with the dedicated control app” on page 55)
BLUETOOTH Status Indicator
REMOTE CONTROL
ON
Not
connected
blinking
Connections
lit
REMOTE CONTROL
OFF
-
No
indicator
Function button functions
These show the functions assigned to the function buttons.
When recording/playback stopped
Total time of current le
Status
Current le
name
Recording format
Available recording time
Function button Function
F1[MENU] Open MENU screen (page 63)
F2[BROWSE] Open BROWSE screen (page 64)
F3[INPUT] Open INPUT SETTINGS screen (page 65)
F4[OUTPUT] Open OUTPUT SETTINGS screen (page 65)
