40
USB
Interface
CD-A580 v2 ........................USB 2.0 FULL SPEED (12 Mbps)
CD-A580 ........................... USB 1.1 FULL SPEED (12 Mbps)
Connector .............................................USB A port
Playback
Frequency response ....................20Hz – 20,000Hz (±2dB)
Signal-to-noise ratio ...............................85dB or more
Format ......................................................MP3
Sampling frequency ..............................16 kHz – 48 kHz
Playback bit rate ...............................8 kbps – 320kbps
Line output (RCA) ...........Maximum output level +6 dBV (2.0 V)
(load impedance of 50kΩ or more)
Recording
Frequency response
CDwUSB ................................20Hz – 15kHz (±3dB)
LINEwUSB ..............................100Hz – 15kHz (±3dB)
Signal-to-noise ratio ...............................85dB or more
Format ......................................................MP3
Sampling frequency .....................................44.1 kHz
Record bit rate .......................................... 128kbps
Line input (RCA) ............Nominal input level −10 dBV (0.316 V)
(input impedance of 50 kΩ or more)
Maximum continuous recording time ................240minutes
Folder levels ............................ Up to 8 levels supported
Headphones
Headphone output connector ................Standard stereo jack
Rated output ......................................10 mW + 10 mW
(CD monitoring, THD+N 0.1%, 32 Ω)
General
Power requirement
Model for Europe .................................AC 230V, 50Hz
Model for USA/Canada ...........................AC 120 V, 60 Hz
Power consumption .......................................... 13W
Dimensions (W × H × D)
483 × 138.5 × 290mm (19" × 5.5” × 11.4”)
(including protrusions)
Weight (Net) ........................................6.0kg (13.2lb)
Operating temperature ..............................+5°C to +35°C
Included Accessories
Remote control (RC-1329) × 1
Batteries (AAA) for remote control × 2
Rackmount screw kit × 1
Owner’s manual (this document, including warranty) × 1
TASCAM ID registration guide × 1 (for CD-A580 v2 only)
Specifications
CD Player
Compatible discs ...................CD/CD-R/CD-RW (12 cm/8 cm)
Disc formats
Audio CD ................................................. CD-DA
Data CD .......................................ISO 9660 Level 1/2
Playable formats
CD-DA
Sampling frequency ....................................44.1 kHz
Quantization bit depth ................................... 16-bit
Number of channels ..........................................2
MP3
Audio modes ..STEREO/JOINT STEREO/DUAL CHANNEL/MONO
Sampling frequency .............................16 kHz – 48 kHz
Bit rate ......................................8 kbps – 320 kbps*
Frequency response ..........................20Hz – 20kHz ±2dB
Total harmonic distortion ...................... 0.02% or less (1kHz)
Signal-to-noise ratio (S/N) ....................87dB or more (IHF-A)
Line output (RCA) ............Maximum output level +6 dBV (2.0 V)
(load impedance of 50kΩ or more)
*DRM (Digital Rights Management) is not supported.
Cassette tape player
Track system .............................4-track, 2-channel stereo
Heads ..............................Record/playback × 1, erase × 1
Type of tape ..................................C-10 to C-90 cassette
Tape speed ............................................4.76 cm/sec.
Motor ......................................... DC servo motor × 1
Pitch control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±10% (playback only)
Wow and flutter ....................................0.25% (W. RMS)
Frequency response (overall) ......50 Hz – 12.5kHz ± 4dB, chrome
50 Hz – 12.5kHz ± 4dB, normal
Signal-to-noise ratio (overall)
59dB (Maximum recording level input, A-weighted)
Rewinding time .......................Approx. 120sec. (with C-60)
Line input (RCA) ..............Nominal input level −4.5 dBu (0.46 V)
(input impedance of 50kΩ or more)
Line output (RCA) ..........Nominal output level −4.5 dBu (0.46 V)
(load impedance of 50kΩ or more)
