Tascam CD-A580 v2 handleiding
Handleiding
Je bekijkt pagina 13 van 44
13
18
Play (
t
) button
This starts cassette tape playback.
Press when a cassette tape is paused to resume playback/
recording.
19
PITCH CONTROL knob
Turn this knob to vary the playback speed (page 25).
20
Pause (J) button
Press this button to pause CD playback. To resume playback,
press this button again.
21
FOLDER ( / ) buttons
Use these buttons to select folders (pages19 and 27).
22
POWER ON START OFF-PLAY-REC (TAPE) switch
Use this switch to set the timer operation mode (off, play or record).
To use this when set to play or record, connect a commercially-
available programmable timer to this unit (page 34).
o Select OFF to not use timer playback or recording.
23
Play (
t
) button
Press this button to start CD playback.
24
Stop (H) button
Press this button to stop CD playback.
25
Skip (.//)/Search (m/,) buttons
Press these buttons to skip through files.
Hold down these buttons to search for part of a file.
26
POWER ON START CD-TAPE-USB switch
Use this switch to set the sound source that is active when the
power is turned on.
Use this switch to set the media used for timer playback/
recording. (The timer recording can only record to cassette tape.)
To use timer playback/recording, connect a commercially-
available programmable timer to this unit (page 34).
27
Pause (J) button
Press this button to pause USB playback or recording.
Press this button again to resume playback or recording.
28
Play (
t
) button
Press this button to start USB playback.
When in USB recording standby, press this to start recording.
29
Stop (H) button
Press this button to stop USB playback.
Press this button also to stop recording to USB.
30
Disc tray
31
USB port
Connect an external USB flash drive here.
32
POWER button
Press this button to turn the unit on or off.
ATTENTION
Never turn the unit off or disconnect a USB flash drive when
it is being accessed, for example, during writing, playback,
recording or the erasure of files.
Doing so could damage the unit and the connected USB
flash drive.
a
Model name (V2)
In order to distinguish it from the original CD-A580, the CD-A580
v2 has “V2” written on the front at the bottom right.
Please be aware that the CD-A580 and CD-A580 v2 have different
specifications for the file names and folder structures used when
saving on USB flash drives (page 28).
14
15 a
16
17
