VII. SPECIFICATIONS
50 W RMS / 80 W Peak
Tweeter : 1” Dome
Mid-woofer : 4” Cellulose pulp
Bookshelf loudspeaker
2 way
Bass-reflex
65 Hz - 20 kHz (±3dB)
87 dB / 1W / 1m
2800 Hz - 12 dB / 12 dB
6 Ω
3,5 kg
60 W RMS / 100 W Peak
Tweeter : 1” Dome
Mid-woofer : 5” Cellulose pulp
Bookshelf loudspeaker
2 way
Bass-reflex
60 Hz - 20 kHz (±3dB)
88 dB / 1W / 1m
2800 Hz - 12 dB / 12 dB
6 Ω
4,3 kg
Spectrum II
X4
Spectrum II
X5
Type
Power
Drive-Units
Frequency response
Sensitivity
Crossover
Nominal impedance
20 - 70 W 20 - 100 WPower amplifier
100 W RMS / 150 W Peak
Tweeter : 1” Dome
Mid-woofer : 2 x 5” Cellulose
pulp
Floorstanding loudspeaker
2½ way
Bass-reflex
50 Hz - 20 kHz (±3dB)
90 dB / 1W / 1m
1800 & 2900 Hz
12 dB / 12 dB / 12 dB
6 Ω
12 kg
Spectrum II
X6
20 - 150 W
W145 x H256 x D198 mm W166 x H322 x D205 mm W166 x H900 x D268 mm
Weight
Black, White Black, White Black, WhiteFinishes
Dimensions
EN
38 39
EN
VI. USE
1. BURNIN PERIOD
When you take them out of the packaging, the Spectrums II loudspeakers are not yet able to repro-
duce with the same efficiency all the sound frequencies they are supposed to play.
The Spectrum II range loudspeakers are complex mechanical assemblies which need a period of
adaptation (“burn-in”) to operate at their best and become acclimatised to the temperature and
humidity conditions of your environment.
This burn-in period may last for some weeks, but you can quicken it by operating the loudspeakers
between 50 and 100 hours consecutively, on a moderate volume and broadcasting a radio station.
We advise increasing this period to 150 hours for the X6 loorstanding loudspeakers, and the XSW8
subwoofer.
2. CHOICE OF CABLES
Choose high quality cables with a cross-section appropriate to their length.
3. CHOICE OF AMPLIFIER
Your setup type (stereo or home-cinema) will determine the choice of the appropriate amplifier.
Your dealer will be able to advise you on the most suitable amplifier for your system.
4. CLEANING INSTRUCTIONS
To improve the lifetime of your loudspeakers, we recommend regular cleaning. A soft cloth will be
enough for dusting. If the loudspeaker is stained, we recommend simply using a damp cloth with
some mild soap if necessary. The front panel can be cleaned with a soft cloth and standard glass
cleaning product.
Never use solvents, detergents, alcohol-based or corrosive products, scrapers or scourers to avoid
any damage on the loudspeaker surface. Keep the loudspeakers away from sources of heat.
