Alarm: Deterrent
Setup: Click the button to change the default spotlight detection area. The
entire view of the camera is enabled, however, you can select particular areas
if you wish (see page 36 - Deterrent Setup).
Schedule: Click the button to change the default spotlight schedule (see
page 37 - Deterrent Schedule).
Sensitivity: This option allows you to change how sensitive the spotlight
will be when your NVR has detected motion. It’s independent of the cam-
era’s sensitivity for detecting motion. As an example, you may want to record
movement happening in the background but you don’t want the spotlight and
or the siren to be triggered until one or more objects gets closer to the cam-
era. For this scenario, you would adjust the sensitivity to 1 or 2.
Light: Click the checkbox to enable the camera’s spotlight.
Duration: This lets you change the length of time the spotlight will remain lit
when motion is detected. Adjust accordingly.
Siren: The camera’s siren is off by default. If the siren is required, click the
drop-down menu to enable it (this function is only available if your camera
has a built-in siren). A warning message will appear on-screen. Click “OK”
to continue.
Enforcer: Click the checkbox to enable the camera’s red and blue lights.
Enforcer Duration: This lets you change the length of time the red and blue
lights will flash when motion is detected.
Regarding the cameras’ light and siren, they are triggered when your
NVR detects motion by the camera and the built-in PIR sensor. They
can also be triggered via the Swann Security app.
The functions available here are for the
NHD-885/887MSFB, NHD-875WLB and En-
forcer series of cameras only. The Enforcer
function will only appear when an Enforcer
camera is connected.
→ Click “Apply” to save settings.
