40
Click for contents
Analytics: LCD (Line Crossing Detection) - Actions
Buzzer: When motion is detected, you can enable the DVR’s buzzer to alert
you for a predetermined time. Click the drop-down menu to select a time.
Record (Record Channel & Analog Channels): This option instructs your
DVR to trigger additional cameras to start recording when motion has been
detected. Click the “Analog Channels” checkbox to select all cameras or click
on the individual camera number that you want to trigger for recording.
Post Recording: This option instructs your DVR to record for a set period of
time after an event has occurred. For most instances, the default selection
will be suitable, however you can change this if you wish.
Show Message: When motion has been detected, the motion icon will ap-
pear on-screen. Click the checkbox if you want to disable this.
Send Email: An email alert will be sent when motion is detected. Click the
checkbox if you want to disable this.
Push: Click the checkbox to receive push notifications via the Swann Security
app.
Picture to Cloud: Click the checkbox to copy snapshots to the cloud via Drop-
box.
Video to Cloud: Click the checkbox to copy video events to the cloud via Drop-
box.
To enable cloud storage (see page 75 - Device: Cloud Storage).
Full Screen: Click the checkbox to view the camera full-screen in Live View
mode when motion has been detected.
Click the “Save” button then click “OK”. Right-click the mouse to exit.
The Push, Picture to Cloud and Vid-
eo to Cloud functions will only ap-
pear when LCD + PIR is selected.
