Drawing an Object Detection Region
IVA (Intelligent Video Analytics) Lines: When enabled, your DVR will deter-
mine which direction a person has entered or exited an object detection re-
gion.
Rule Number: Click the drop-down menu to select the rule number that you
want to create. Up to four object detection regions can be drawn.
Rule Switch: Leave this enabled.
Rule Type: Only one rule type is available.
Taken & Left: An event will occur when an object is taken or removed and or
when an object is left within the object detection region.
Using the mouse, create four points to draw an object detection region (it
can be drawn at any size). Your DVR does not allow lines to be crossed when
drawing a detection region. Make sure the detection region is greater than or
equal to the size of the detected object.
As illustrated above left, click once at the start point, then move right and
click once to create the second point. Move the mouse down and click once to
create the third point, then move left and click once to create the fourth point.
Remove: See the above right example.
Remove All: Click this to remove all object detection regions.
Save: Click this to save any changes made, then click “OK” to continue.
Right-click to exit.
1 Taken & Left
To remove an object detection region: Click the rule num-
ber checkbox to select, then press the “Remove” button.
Click “Remove All” to delete all regions drawn.
1 Taken & Left
