Drawing a Perimeter Intrusion Region
Rule Number: Click the drop-down menu to select the rule number that you
want to create. Up to four perimeter intrusion regions can be drawn.
Rule Switch: Leave this enabled.
Rule Type: There are three rule types that can be selected. Select the appro-
priate rule for the region created (each region can have a different rule).
A->B: Motion is detected when an object has crossed the line from direction
A only.
B->A: Motion is detected when an object has crossed the line from direction
B only.
A<->B: Motion is detected when an object has crossed the line from both
directions.
Using the mouse, you need to create four points to draw a perimeter intru-
sion region (it can be drawn at any size). Your DVR does not allow lines to be
crossed when drawing an intrusion region.
As illustrated above left, click once at the start point then move right and
click once to create the second point. Move the mouse down and click once to
create the third point then move left and click once to create the fourth point.
Remove: See above right example.
Remove All: Click this to remove all perimeter intrusion regions.
Save: Click this to save any changes made then click “OK” to continue.
Right-click to exit.
1
A B
A
B
A
B
A
B
To remove a perimeter intrusion region: Click the rule
number checkbox to select, then press the “Remove” but-
ton. Click “Remove All” if multiple regions are drawn.
1
A B
A
B
A
B
A
B
