Drawing a Pedestrian Detection Region
Rule Switch: Leave this enabled.
Using the mouse, you need to create four points to draw a pedestrian detec-
tion region (it can be drawn at any size). Your NVR does not allow lines to be
crossed when drawing a detection region. Make sure the detection region is
greater than or equal to the size of the detected object.
As illustrated above left, click once at the start point, then move right and
click once to create the second point. Move the mouse down and click once to
create the third point, then move left and click once to create the fourth point.
Remove: See the example above right.
Remove All: Click this to remove all pedestrian detection regions.
Save: Click this to save any changes made, then click “OK” to continue.
Right-click to exit.
1
To remove a pedestrian detection region: Click the rule
number checkbox to select then press the “Remove” button.
