Camera Matrix: Record Mainstream

NHD-865MSB NHD-866MSD NHD-875ER NHD-875WLB NHD-876DER NHD-876MSD NHD-885MSB NHD-885MSFB NHD-886MSD

Resolution 2592 x 1944 2592 x 1944 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160

F

PS 15 15 Auto Auto Auto Auto 15 15 15

V

ideo Encode Type (by default) H.265 H.264 H.264 H.265 H.265 H.265 H.265 H.265 H.265

B

itrate Control (by default) CBR CBR VBR (CBR not avail) VBR (CBR not avail) VBR (CBR not avail) VBR (CBR not avail) CBR CBR CBR

V

ideo Quality (for VBR) Highest Highest Higher Highest Highest Highest Highest Highest Highest

B

itrate Mode Predefined Predefined User-defined User-defined User-defined User-defined Predefined Predefined Predefined

B

itrate (by default) 4096 (8192 max) 4096 (8192 max) 6144 6144 6144 6144 6144 (8192 max) 6144 (8192 max) 6144 (8192 max)

A

udio (by default) Enabled Enabled Enabled Not enabled Enabled Enabled Enabled Enabled Enabled

I

Frame Interval 15 30 - - - - 30 30 30

N

HD-887MSB NHD-887MSFB NHD-888MSD NHD-900BE NHD-900DE NHD-900PT NHD-1200BE NHD-1200DE NHD-1200D

Resolution 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 3840 x 2160 4096 x 3072 4096 x 3072 4096 x 3072

F

PS 15 15 15 20 15 15 15 15 15

V

ideo Encode Type (by default) H.264 H.264 H.265 H.265 H.265 H.265 H.265 H.265 H.265

B

itrate Control (by default) CBR CBR CBR CBR CBR CBR CBR CBR CBR

V

ideo Quality (for VBR) Highest Highest Highest Highest Highest Highest Highest Highest Highest

B

itrate Mode Predefined Predefined Predefined Predefined Predefined Predefined Predefined Predefined Predefined

B

itrate (by default) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max) 6144 (8192 max)

A

udio Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled

I

Frame Interval 30 30 30 40 30 30 30 30 30

To find out which camera model you have, in the Main Menu, go to Display > IP Channels. Your model is listed under “Device Type”.
