37
air inlet and outlet are not blocked. Ensure the electric hob is in good work
state. As shown below:
Note: The safety distance between the hotplate and the cupboard above
the hotplate should be at least 760mm.
A(mm)
B(mm)
C(mm)
D
E
760mm
50mm minimal
20mm minimal
Air intake
Air exit 5mm
Note: The illustration is a reference image, your device may differ.
Installing the foam gasket
Before inserting the hob into the opening in the kitchen worktop, the supplied
foam gasket (in a plastic bag) must be attached to the lower side of the ceramic
glass.
Do not install the hob without the foam gasket!
The gasket should be attached to the hob in the following
method:
▪ Remove the protective film from the gasket.
▪ Then attach the gasket to the lower side of the glass, next to the edge.
