GET THE BEST FROM THE BEST
The SF18650B is a Lithium Ion protected 18650 battery with micro
USB charge capability. This allows the user to conveniently charge
the battery using any USB power source such as a USB wall charger,
computer/laptop, power bank, or automotive USB port. Additionally,
an external 18650 compatible CC-CV cradle charger can be used to
charge the battery; possibly at a faster rate if so equipped.
OPERATION
The SF18650B can be used as a standard protected 18650 in many
applications with one advantage; the battery can be charged directly
through the micro USB port, requiring no external charge cradle.
The SF18650B comes with a 6 inch USB type A plug to micro USB
type B plug, with the micro USB plug being the end inserted into the
battery. The battery side includes a micro USB type B receptacle.
Once the cable is plugged into the battery and a power source, the
2 LED indicators display the current charge state: RED for charging
and GREEN for fully charged. The battery can be left connected to
the charge source indefinitely as the internal charge algorithm will
restart the charge cycle once the cell voltage drops below 4-5% of
the float voltage. The typical charge time for charging via the micro
USB port for fully depleted battery can be over 5 hours. The user has
an option of charging the battery with an external charger to shorten
the total charge time.
The quiescent drain on the battery from the protection circuit is 40uA,
which in addition to the cell self-discharge, allows a fully charged
battery to be stored for 2-3 years and still maintain usable capacity
SAFETY
The internal protection circuit integrated within the battery
assembly provides the following safety features:
-Over-charge
-Over-discharge
-Short Circuit
-Under-voltage
-Over-voltage
ENVIRONMENTAL
Storage Temperature Range: 0-35°C. 60±25% RH
Charging: 0°C-45°C, 65%±25%RH
Discharging: -20°C-+60°C, 65%±25%RH
Note: The battery’s metal button top also functions as a heatsink
during USB charging, which may result in it being very warm to the
touch during the high charge rate period.
