►PCI Express 0 / PCI Express 1 / PCI Express 2 / PCI Express 3 / PCI
Express 4 / PCI Express 5
Note: The number of PCIe slots and the slot naming can differ depending on the PCIe
devices connected to your motherboard.
Bifurcation
This feature is CPU-dependent. Use this feature to configure the PCIe Bifurcation setting for
the PCIe port you specified. The options are Auto, x4x4x4x4, x4x4x8, x8x4x4, x8x8, and
x16.
Intel VMD Technology
When this feature is set to Enabled, VMD support will be automatically enabled when a
VROC key is detected by the BIOS. The options are Disabled and Enabled.
►PCI Express 0 Port A/B/C/D/E/F/G/H – PCI Express 5 Port
A/B/C/D/E/F/G/H
Requested Link Speed
Use this feature to configure the link speed for the PCIe port you specified. The options are
Auto, Gen 1 (2.5 GT/s), Gen 2 (5 GT/s), Gen 3 (8 GT/s), Gen 4 (16 GT/s), and Gen 5 (32
GT/s).
The following information is displayed.
l
Max Link Width
l
Current Link Width
l
Current Link Speed
Data Link Feature Exchange
Use this feature to enable the data link feature negotiation in the Data Link Feature
Capabilities (DLFCAP) register. The options are Disabled and Enabled.
PCIe Port Max Payload Size
Use this feature to configure the maximum payload size supported in Direct Media
Interface (DMI) device capabilities register for the device installed in the PCIe port. The
options are 128B, 256B, 512B, and Auto.
93
X14DBT-FAP/-FLAP: UEFI BIOS
