Je bekijkt pagina 13 van 167
Figure 1-2. X14DBG-MAP Motherboard Layout
Notes:
l
For detailed information on jumpers, connectors, and LED indicators, see "Component
Installation" on page 26.
l
"■" indicates the location of pin 1.
l
Components not documented are for internal testing purposes only.
l
Use only the correct type of onboard CMOS battery as specified by the manufacturer.
To avoid possible explosion, do not install the onboard battery upside down.
Quick Reference Table
Jumper Description Jumper Setting
JBT1 CMOS Clear Open (Normal)
13
X14DBG-MAP: Introduction
