Motherboard Features
Motherboard Features
Processor
l
Supports dual Intel Xeon
®
6700/6500-series Processors with P-cores and Intel Xeon 6700-
series Processors with E-cores (in Socket E2 LGA 4710) with four UPIs (2.0, 24 GT/s max.)
and a thermal design power (TDP) of up to 350 W
Memory
l
Supports up to 8 TB of RDIMM DDR5 ECC memory with speeds of up to 6400 MT/s (1DPC)
and MRDIMM memory with speeds of up to 8000 MT/s (1DPC) in 32 DIMM slots total for two
processors. Memory speed and capacity support depends on the processors used in the
system.
DIMM Size
l
Up to 256 GB at 12 V DDR5
Note: For the latest processor/memory updates, please refer to our website at
https://www.supermicro.com/en/products/motherboards.
Expansion Slots
l
Two MCIO 5.0 x8 connectors supported by CPU1 (for the front riser card)
l
Two MCIO 5.0 x8 connectors supported by CPU2 (for the front riser card)
l
16 MCIO 5.0 p16-x8 connectors supported by PLX switches (for the front I/O module)
l
Four MCIO 5.0 p16-x8 connectors supported by PLX switches, each with support of two PCIe 5.0
x4 NVMe connections
l
One MCIO 5.0 x4 connector supported by CPU1, with support of two PCIe 4.0 x4 NVMe
connections via AOM-S3808NI-4NM
l
One MCIO 5.0 x4 connector (for AOM-GP805-IO, featuring Intel X710)
Baseboard Management Controller (BMC)
l
ASPEED AST2600 BMC
l
One dedicated BMC LAN (via AST2600 BMC HW RoT 2.0)
Graphics
l
Graphics controller via ASPEED AST2600 BMC
16
X14DBG-LC+: Introduction
