Chapter 1: Introduction
Note: The table above is continued on the next page.
Motherboard Features
CPU
• Intel® Xeon® E3-1200 v6/v5, 7th/6th Gen Core™ i3, Pentium, and Celeron series processor in an LGA1151 (H4) socket
with 80W max TDP.
Memory
• Four (4) 288-pin DIMM slots support up to 64 GB of SDRAM 72-bit DDR4 unbuffered ECC 2400/2133/1866/1600/1333MHz
memory.
DIMM Size
• 16GB, 8GB, and 4GB, up to 64GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel® C236 PCH (X11SSM/-F)
• Intel® C232 PCH (X11SSL/-F)
Expansion Slots
• Two (2) PCI Express 3.0 x4in p15-x8 slots (PCH slots 4 & 5) [slot 4 on X11SSM(-F) only]
• One (1) PCI Express 3.0 x8in x16 slot (CPU slot 6)
• One (1) PCI Express 3.0 p15-x8 slot (CPU slot 7)
Network
• Intel i210 AT Gigabit Ethernet Controllers for LAN1/LAN2
Baseboard Management Controller (BMC)
• Aspeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0 (-F versions only)
• One (1) IPMI_dedicated_LAN located on the rear IO back panel (-F versions only)
Graphics
• Graphics controller via Aspeed AST2400 BMC
I/O Devices
• Serial (COM) Port
• One (1) serial port on the rear I/O panel (COM1)
• One (1) front accessible serial port header (COM2) (X11SSM/-F only)
• SATA 3.0
• Six (6) SATA 3.0 ports (I-SATA 0-5)
• Two (2) additional SATA 3.0 ports (I-SATA6-7) (X11SSM/-F only)
• Two (2) SuperDOM connectors (I-SATA0 & I-SATA1)
• RAID (PCH) • RAID 0, 1, 5, and 10
Motherboard Features
