13
Chapter 1: Introduction
Note: Table is continued on the next page.
Quick Reference Table
Jumper Description Default Setting
JI
2
C1/JI
2
C2 SMB to PCI Slots Pins 1-2 (Enabled)
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 Clear CMOS See Chapter 2
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/LAN2 Enable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Enable Pins 1-2 (Reset)
LED Description Status
LE1 Rear UID LED Bllue: On; Unit Identied
LEDBMC BMC Heartbeat LED Green: Blinking; BMC Normal
LEDPWR Onboard Power LED Green: Solid On; Power On
Connector Description
BT1 Onboard Battery
COM1 COM1 Port Header
COM2 COM2 Port Header [X11SSM(-F) only]
FAN1-FAN4, FANA System/CPU Fan Headers
IPMI LAN Dedicated IPMI Gigabit (RJ45) Port (X11SSM-F & X11SSL-F only)
I-SATA0-I-SATA5 (Intel PCH) Serial ATA (SATA) 3.0 Ports
I-SATA6 & I-SATA7 (Intel PCH) Serial ATA (SATA) 3.0 Ports [X11SSM(-F) only]
I-SGPIO 1/2 Serial Link General Purpose I/O Connection Headers 1/2
JD1 Speaker/Power LED Indicator
JF1 Front Control Panel Header
JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JPI
2
C1 Power System Management Bus (Power SMB)
JOH1 Overheat LED Indicator
JPWR1 24-pin ATX Main Power Connector (Required)
JPWR2 +12V 8-pin Power Connector (Required)
JSD1/JSD2 SATA DOM (Device_On_Module) Power Connectors
JSTBY1 Inject External P5V_STBY Power
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 Unit Identier Switch
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
PCI-E (CPU) Slot 7 PCI-Express 3.0 p13-x8 Slot
