Chapter 1: Introduction
1-7
Ethernet LAN Ports/IPMI-LAN on the IO Backplane
•Two (2) Ethernet LAN ports (LAN1/LAN2) for each
node, (P1-LAN1/LAN2 for Node 1; P2-LAN1/LAN2
for Node 2);
•Four (4) GLAN ports onboard
One (1) shared IPMI-dedicated LAN port supported by BMC
controller chips for remote console interface. The IPMI-LAN
is shared between Node 1 and Node 2
One (1) Onboard LAN Ethernet switch that allows multiple
devices to access the Ethernet simultaneously
BIOS •One (1) 128 Mb AMI BIOS
®
SPI Flash BIOS chip
for each node;
•Two (2) AMI BIOS
®
SPI Flash BIOS chips onboard
Play-and-Plug (PnP), PCI 2.3, ACPI 1.0/2.0/3.0, USB/KVM,
SMBIOS 2.3, RTC (Real-Time Clock), and Node Manage-
ment
Power Conguration ACPI/ACPM Power Management
Main Switch Override Mechanism
Power-On Mode for AC Power Recovery
PC Health
Monitoring
CPU Monitoring
Onboard voltage monitors for +3.3V, +5V, +12V, 3.3V
Standby, VBAT, Memory, Chipset, CPU Core
CPU 3-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor 2 (TM2) support
System Management PECI (Platform Environment Conguration Interface) 2.0
System resource alert via SuperDoctor
®
III
SuperDoctor
®
III, Watch Dog, NMI
CD Utilities BIOS ash upgrade utility
Other ROHS (Full-Compliance, Lead-Free)
Dimensions SMC-proprietary form factor (18.5" x 4.6") (469.90 mm x
116.84 mm)
