13

Chapter 1: Introduction

Quick Reference Table

Jumper Description Default Setting

JBT1 CMOS Clear Open: Normal, Closed: Clear CMOS

JI2C1, JI2C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled)

JNS1 Mini-SAS HDD NVMe/SATA Mode Select Pins 1-2: SATA (Default), Pins 2-3: NVMe

JPG1 Onboard VGA Enable Pins 1-2 (Enabled)

JPL1 LAN1/2/3/4 Enable Pins 1-2 (Enabled)

JPME2 Manufacturing Mode Select Pins 1-2 (Normal)

JPUSB1 USB Wake Up Pins 1-2 (Enabled)

JWD1 Watch Dog Pins 1-2 (Reset)

LED Description Status

LED1 Power LED Solid Green: Power On

LED2 UID LED Solid Blue: Unit Identied

LED3 Overheat/PWR Fail/Fan Fail

Solid Red: Overheat

Blinking Red: PWR Fail or Fan Fail

LEDM1 BMC Heartbeat Blinking Green: BMC Normal

Connector Description

BT1 Onboard Battery

COM1 COM Header

FAN1 - FAN4, FANA, FANB System/CPU Fan Headers

IPMI_LAN Dedicated IPMI LAN Port

I-SATA0-3, I-SATA4-7 Eight Intel® PCH SATA 3.0 Ports or Two NVMe U.2 Ports

(See jumper JNS1 setting)

JD1 PWR LED/Buzzer Header (Pins 1-4: PWR LED, Pins 5-7: Buzzer)

JF1 Front Control Panel Header

JGP1 General Purpose I/O Header

JIPMB1 System Management Bus Header (for IPMI only)

JL1 Chassis Intrusion Header

JLANLED1 LAN1 - LAN4 Activity LED Header

JMD1 M.2 PCI-E 3.0 x4/S-SATA5 Connector (M-Key 2280)

JMD2 M.2 PCI-E 3.0 x2/S-SATA4 Connector (B-Key 3042)

JMD1_SRW1, JMD2_SRW1 M.2 Holding Screws

JMP1 Mini PCI-E x1 Connector

JMP1_SRW1 Mini PCI-E x1 Connector Holding Screw

JNVI2C1 NVMe I

2

C Header

JPI2C1 Power I

2

C System Management Bus (Power SMB) Header

JPH1 4-pin Power Connector for HDD use

JPW1 24-pin ATX Main Power Connector

JPV1 12V 8-pin DC Power Connector (Required to provide extra power to CPU, or as

alternative power for special enclosure when the 24 pin ATX power is not in use)
