SuperBlade Server SBI-420P-1(C2/T3)N User's Manual

Quick Reference

Jumper Description Default Setting

JBT1 CMOS Clear Open (Normal)

JPME1 ME Manufacturing Recovery Pins 1-2 (Normal)

Connector Description

BT1 Onboard CMOS battery

CPLD0 Complex Programmable Logic Device (CPLD) chip

FAN1 Cooling fan header reserved for liquid cooling

HDD0/HDD1 Front accessible Hard Driver Connector #0/Hard Driver Connector #1

HDD2_PWR Power connector for HDD 2

JBT1 Contacts for CMOS Clear

JFP1 Front Panel Control board with KVM & USB 2.0 support (via Cable CBL-0218L)

JLED HDD2 SATA Activity LED

JM2-1 & M.2 MH M.2 slot (PCIe 4.0 x4) and M.2 Mounting Hole (M.2 MH)

JTPM1 Trusted Platform Module/Port 80 connector

MEZZ1/MEZZ2 PCI Mezzanine Card Connector 1/Mezzanine Card Connector 2

MP1 Onboard 25G midplane

PWR1 Motherboard Power connector

I-SATA 1 Intel PCH SATA 3.0 port (with RAID 0, 1, 5, 10)

VROC (JRK1) Intel VROC key header for NVMe RAID support

LED Description State: Status

DA4 HDD0 Heartbeat LED Green: HDD0 Normal; Red: HDD0 Failure

DA5 HDD1 Heartbeat LED Green: HDD1 Normal; Red: HDD1 Failure

DA6 HDD0 Activity LED Blue: HDD0 Active

DA7 HDD1 Activity LED Blue: HDD0 Active

LED1 M.2 Activity LED Green: M.2 Normal

LEDM1 BMC Activity LED Green: BMC Normal
