Chapter 1: Introduction

Quick Reference

Jumper Description Default Setting

JBT1 Onboard CMOS Clear Open (Normal)

JPG1 VGA Enable/Disable Pins 1-2 (Enable)

JPME2 Manufacturing Mode Pins 1-2 (Normal)

JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enable)

JWD1 Watchdog Timer Pins 1-2 (Reset)

Connector Description

BT1 Onboard CMOS Battery

I-SATA1 SATA 3.0 Port

J1 Chassis Backplane Connector

J2 PCIe 4.0 x8 SlimSAS Connector

J6 CPLD JTAG Header

M.2-H M.2 M-Key PCIe 4.0 or SATA 3.0 Connector (2280/22110)

JKVM1 VGA/USB Module Connector

JREK1 Intel RAID Key Header

JTPM1 Trusted Platform Module (TPM)/Port 80 Connector

JSD1 SATA DOM Power Connector

JUSB1 Internal USB 3.2 Gen 1 Type-A Port

MH1 – MH4 Mounting Holes

SRW_1 – SRW_2 M.2 Mounting Holes

LED Description State: Status

LED1 BMC Heartbeat LED Blinking Green: BMC Normal

LED2 BMC Error LED Red: Power Fail or FAN Fail

LED DDR5 PWRFAIL LED Power Fail
