Chapter 1: Introduction

Quick Reference

Jumper Description Default Setting

JBR1 BIOS Recovery Pins 1-2 (Normal)

JBT1 CMOS Clear Open (Normal)

JPG1 VGA Enable/Disable Pins 1-2 (Enabled)

JPME1 ME Recovery Pins 1-2 (Normal)

JPME2 ME Manufacturing Mode Pins 1-2 (Normal)

JPT1 Onboard TPM 2.0 Enable/Disable Pins 2-3 (Disabled)

JWD1 Watchdog Timer Pins 1-2 (Reset)

Connector Description

BT1 Onboard Battery

I-SATA0 SATA 3.0 Port

J3 M.2 Connector

J21

Slim SAS Connector (connects U.2 NVMe drives on AOM-BPNIO-MSH2

through Slim SAS cable)

JRK1 Intel RAID Key Header

JSD1 SATA DOM Power Connector

JTPM1 Trusted Platform Module/Port 80 Connector

SRW1, SRW2 M.2 Holding Screws

LED Description State: Status

BMCL_HB_LED1 BMC Heartbeat LED Blinking Green: BMC Normal
