Chapter 1: Introduction

Quick Reference

Jumper Description Default Setting

JBT1 Onboard CMOS Clear Open (Normal)

JPME2 Manufacturing Mode Pins 1-2 (Normal)

JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enable)

JWD1 Watchdog Timer Pins 1-2 (Reset)

Connector Description

BT1 Onboard CMOS Battery

CN1 MCIO Connector

CN2 MCIO Connector

I-SATA0 SATA DOM Port

JKVM1 VGA/USB Module Connector

JMD1 M.2 Slot for 2280

JMD1_SRW1 M.2 Mounting Hole

JPV1 Gold Finger to JPV2 of Node 1 or Backplane through AOM-BPNIO-GFR for Power Delivery

JPV2 12 V Power Straddle Connector to Node 2

JSD1 SATA DOM Power Connector

JSMB1 System Management Bus Header

JTPM1 Trusted Platform Module (TPM)/Port 80 Connector

JUSB1 Internal USB 3.0 Type-A Port for Debugging

J25 Power Connector for HDD Backplane

M.2-HC M.2 M-Key PCIe 4.0 or SATA 3.0 Connector (2280)

MH1 – MH5 Motherboard Mounting Holes

LED Description Status

LED1 BMC Heartbeat LED Blinking Green: BMC Normal
