Chapter 1: Introduction
1-5
H8SGL(-F) Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear (See Section 2-7)
JCF1 Compact Flash Master/Slave Closed (Master)
JD1 Power LED
Pins 1-3: Power LED
Pins 4-7: Speaker
JI2C1/JI2C2 I2C to PCI-E Slot Enable/Disable Both Open (Disabled)
JPB BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN 1 Enable/Disable Pins 1-2 (Enabled)
JPL2 LAN 2 Enable/Disable Pins 1-2 (Enabled)
JPUSB1 USB Power Pins 1-2: Dual Power
Pins 2-3: Standalone Power
JWD Watch Dog Pins 1-2 (Reset)
LED Description
LAN Ports LEDs for the LAN Ethernet ports
Dedicated IPMI LAN LEDs for the dedicated IPMI LAN Ethernet port (H8SGL-F only)
DP3 LED for Serverboard Power-On
